MarGear GMX 600 W | Universal Gear Measuring Center

DESCRIPTION

• The new GMX 600 W cylinder coordinate measuring center

• The successful combination of diameter, gear and form measurement in one setup saves on additional investment and maintenance costs as well as time

• Full functionality as gear or cylinder coordinate measuring center and form tester up to an outside diameter of 600 mm

• The MarGear GMX 600W, as a complete solution, can also be used for measuring hydraulic parts, crankshafts, camshafts and pistons

• Combining gear measuring tasks with various diameter, form & position features has never been easier. Due to high precision scales and smooth drive units, even contour measurements and waviness analysis are possible

• With over 6000 units sold, the MarWin environment is a clear and simple way of creating complete programs in Teach In mode

• Improves programming efficiency and reduces the possibility of incorrect use

• Proven GMX realtime machine error correction is also used for positioning movements with the new MarEcon control unit, guaranteeing maximum speed and precision throughout the entire measuring and movement sequence

• The high-precision 3D scanning sensor combined with fully automated swivelling unit leads to highest flexibility even regarding future measuring tasks

• The use of standardized interfaces leads to universal communication in terms of Industry 4.0. The following interfaces are available:

• GDE interface for inner and outer gears

• Data export to QS-STAT

• ASCII
